J3001
Pin Number Signal name
4 RGV16(VM)
J3002
Pin Number Signal name
1 TH
2 GND
3 Vout
4 +5V
J3003
Pin Number Signal name
1 /MAKITORI_UNIT
2 /MAKITORI_LOCK_SENS
3 /MAKITORI_VCC_ON
4 MAKITORI_VM_ON
5 /MAKITORI_ENB
6 PHOTO_SENS_OUT
7 VM_26V
8 VM_26V
9 VMGND
10 VMGND
11 +5V
12 N.C.
13 N.C.
14 N.C.
J3150
Pin Number Signal name
1 IN 3+
2 IN 3-
3 IN 1-
4 IN 2+
5 IN 1+
6 IN 2-
7 VM_GND
8 +5V
9 OUT B
10 OUT B
11 OUT A
12 OUT A
13 OUT C
14 OUT C
J3201
Pin Number Signal name
A1 TANK_CLK
A2 GND
A3 OUT_TANK_DAT2
A4 TANK_+3.3V
A5 OUT_TANK_DAT1
A6 OUT_TANK_DAT0
A7 GND
A8 OUT_INK_DETECT0
A9 OUT_INK_DETECT1
A10 OUT_INK_DETECT2
A11 OUT_TANK_DAT5
A12 OUT_TANK_DAT4
6-6
IN/OUT Function
OUT Power supply(+32v)
T-6-14
IN/OUT Function
IN Thermister output signal
- GND
IN Temperature/humidity sensor output signal
OUT Power supply(+5v)
T-6-15
IN/OUT Function
IN Media take-up paper detection sensor
IN Media take-up on/off sensor output signal
OUT Power supply ON signal
OUT Power supply(+26V)
OUT Media take-up drive enable signal
IN Media take-up paper detection sensor output signal
OUT Power supply(+26V)
OUT Power supply(+26V)
- GND
- GND
OUT Power supply(+5V)
- N.C
- N.C
- N.C
T-6-16
IN/OUT Function
IN Hole sensor input signal 3+
IN Hole sensor input signal 3-
IN Hole sensor input signal 1-
IN Hole sensor input signal 2+
IN Hole sensor input signal 1+
IN Hole sensor input signal 2-
- GND
OUT Power supply (+5V)
OUT Motor output signal B
OUT Motor output signal B
OUT Motor output signal A
OUT Motor output signal A
OUT Motor output signal C
OUT Motor output signal C
T-6-17
IN/OUT Function
OUT Ink tank clock signal
- GND
IN/OUT Ink tank data signal 2
OUT Power supply(+3.3V)
IN/OUT Ink tank data signal 1
IN/OUT Ink tank data signal 0
- GND
IN Ink detection sensor output signal 0
IN Ink detection sensor output signal 1
IN Ink detection sensor output signal 2
IN/OUT Ink tank data signal 5
IN/OUT Ink tank data signal 4
