Canon imagePROGRAF IPF8400 Service Manual page 261

Print item
COUNTER EXCHANGE MTC EXC.
HEAD L EXC.
HEAD R EXC.
BOARD EXC.(M/
B)
PARTS Wia-1
EXC.
PARTS Wia-3
EXC.
PARTS Wia-4
EXC.
PARTS Wia-5
EXC.
PARTS Wia-6
EXC.
PARTS CR-1
EXC.
PARTS CR-2
EXC.
PARTS CR-3
EXC.
PARTS CR-4
EXC.
PARTS CR-5
EXC.
PARTS PG-1
EXC.
PARTS HMa-1
EXC.
PARTS MT-1
EXC.
PARTS PL-1
EXC.
PARTS Mi-1
EXC.
PARTS MS-1
EXC.
DETAIL-CNT MOVE PRINTER Count of secondary transportation
MEDIACONFIG-
CNT
N-INKCHK PC,
C, MBK, Y, M,
PM, R, G, B, PGY,
GY, BK
Print content
Maintenance cartridge replacement count
Printhead L replacement count
Printhead R replacement count
Main controller PCB replacement count
Wia-1 (waste ink box unit) replacement count
Wia-3 (platen ink box unit) replacement count
Wia-4 (platen ink box unit) replacement count
Wia-5 (platen ink box unit) replacement count
Wia-6 (suction fan unit) replacement count
CR-1 (carriage unit bushing) replacement count
CR-2 (linear encoder sensor/linear scale/shaft cleaner)
replacement count
CR-3 (carriage height changing cam) replacement count
CR-4 (ink tube unit/flexible cable unit) replacement count
CR-5 (multi sensor) replacement count
PG-1 (purge unit) replacement count
HMa-1 (head management sensor) replacement count
MT-1 (carriage motor) replacement count
PL-1 (feed motor) replacement count
Mi-1 (mist fan) replacement count
MS-1 (multi sensor) replacement count
Count of media registered by media editor
Count of turning off the ink remaining level detection for
each color
Printed value
Unit: times
Unit: times
