Chapter 8
Display message
! Do not pull out ink tank.
(Change to the following message)
! Do not use removed ink tanks in other
printers.
! Do not pull out ink tank.
(Change to the following message)
! Do not use removed ink tanks in other
printers.
Remaining level of the ink cannot be
correctly detected.
Check ink tank.
No ink tank loaded.
Press OK and check ink tank.
Remaining level of the ink cannot be
correctly detected.
Check ink tank.
No ink tank loaded.
Press OK and check ink tank.
Remaining level of the ink cannot be
correctly detected.
Check ink tank.
No ink tank loaded.
Press OK and check ink tank.
No ink tank loaded.
Press OK and check ink tank.
No ink tank loaded.
Press OK and check ink tank.
No ink tank loaded.
Press OK and check ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Ink tank error.
Press OK and replace ink tank.
Maintenance cartridge full.
Replace the maintenance cartridge.
No Maintenance Cartridge capacity.
Replace the maintenance cartridge.
No maintenance cartridge.
Check the maintenance cartridge.
Maintenance cartridge problem.
Replace the maintenance cartridge.
Maintenance cartridge problem.
Replace the maintenance cartridge.
Push paper a little
Manual printing is selected, but a roll is
loaded.
Press Load/Eject and remove the roll.
8-14
Code* Condition detected
03830106-25B0 MBK ink tank detachment (when using the
refill ink tank)
03830106-25B1 MBK2 ink tank detachment (when using
the refill ink tank)
03830107-251A Unidentified status of R ink tank (refill ink
tank detection)
03830107-252A R ink tank not installed.
03830108-251C Unidentified status of G ink tank (refill ink
tank detection)
03830108-252C G ink tank not installed
03830109-251B Unidentified status of B ink tank (refill ink
tank detection)
03830109-252B B ink tank not installed.
03830112-2524 PM ink tank not installed.
03830113-2525 PC ink tank not installed.
03830115-2529 PGY ink tank not installed.
03830201-2541 Y ink tank ID error
03830202-2542 M ink tank ID error
03830203-2543 C ink tank ID error
03830204-2540 BK ink tank ID error
03830205-2548 GY ink tank ID error
03830206-2546 MBK ink tank ID error
03830206-2547 MBK2 ink tank ID error
03830207-254A R ink tank ID error
03830208-254C G ink tank ID error
03830209-254B B ink tank ID error
03830212-2544 PM ink tank ID error
03830213-2545 PC ink tank ID error
03830215-2549 PGY ink tank ID error
03841001-2819 Maintenance cartridge full
03841001-281B Not enough space in the maintenance
cartridge prior to cleaning
03841101-2818 Maintenance cartridge not installed.
03841201-2816 Maintenance cartridge EEPROM error
03841201-2817 Maintenance cartridge ID error
03860001-2E06 Waiting for manual feed paper to be
inserted.
03860001-2E0C Data with a cut sheet specification has been
received when roll media are loaded.
Action
Install the detached ink tank.
Install the detached ink tank.
Invalidate the ink remaining detection function or
replace the ink tank.
Install a R ink tank.
Invalidate the ink remaining detection function or
replace the ink tank.
Install a G ink tank.
Invalidate the ink remaining detection function or
replace the ink tank.
Install a B ink tank.
Install a PM ink tank.
Install a PC ink tank.
Install a PGY ink tank.
Replace with a valid Y ink tank.
Replace with a valid M ink tank.
Replace with a valid C ink tank.
Replace with a valid BK ink tank.
Replace with a valid GY ink tank.
Replace with a valid MBK ink tank.
Replace with a valid MBK ink tank.
Replace with a valid R ink tank.
Replace with a valid G ink tank.
Replace with a valid B ink tank.
Replace with a valid PM ink tank.
Replace with a valid PC ink tank.
Replace with a valid PGY ink tank.
Renew the maintenance cartridge.
Replace the maintenance cartridge.
Install the maintenance cartridge.
Renew the maintenance cartridge.
Renew the maintenance cartridge.
Push the cut sheet a little.
Load cut sheets at the paper tray port.
