J1102
Pin Number Signal name
69 AD6
70 AD5
71 AD4
72 GND
73 AD3
74 AD2
75 AD1
76 AD0
77 GND
78 HDD_LED
79 +5V
80 +5V
81 +5V
82 +3.3V
83 +3.3V
84 +3.3V
85 GND
86 GND
87 GND
88 GND
J1201
Pin Number Signal name
1 GND
2 TXP
3 TXN
4 GND
5 RXN
6 RXP
7 GND
J1202
Pin Number Signal name
1 DASPN
2 +5V
3 GND
J1801
Pin Number Signal name
1 RGV20(+5V)
2 RGV20(+5V)
3 RGV20(+5V)
4 GND
5 GND
6 GND
7 VM
8 VM
9 VMGND
10 VMGND
11 VM_ENB
12 AFCONT
J2402
Pin Number Signal name
1 INKBENM2_AM
2 INKBENM2_AP
3 SNS3V
IN/OUT Function
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
- GND
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
IN/OUT Address and data signal
- GND
- N.C.
OUT Power supply(+5V)
OUT Power supply(+5V)
OUT Power supply(+5V)
OUT Power supply(+3.3V)
OUT Power supply(+3.3V)
OUT Power supply(+3.3V)
- GND
- GND
- GND
- GND
T-6-3
IN/OUT Function
- GND
OUT Transmission Data
OUT Transmission Data
- GND
IN Receive Data
IN Receive Data
- GND
T-6-4
IN/OUT Function
IN Access signal
IN Power supply(+5V)
- GND
T-6-5
IN/OUT Function
IN Power supply(+5V)
IN Power supply(+5V)
IN Power supply(+5V)
- GND
- GND
- GND
IN Power supply(+32V)
IN Power supply(+32V)
- GND
- GND
OUT VM enable signal
OUT Normal/Power saving switch signal
T-6-6
IN/OUT Function
OUT Left valve motor drive signal AM
OUT Left valve motor drive signal AP
OUT Power supply(+3.3V)
