Screen 1, Screen 2 and Screen 3 are selectable with the
These screens display the associated sensor status as listed in the table below.
Display
position
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
7-14
and keys.
Sensor name
Pump Cam Sensor
Valve open/closed detection sensor (R)
Agitation cam sensor (L)
Agitation cam sensor (R)
(Not Used)
Lift cam sensor
Feed roller HP sensor
Upper cover lock switch
Carriage cover sensor
Ink tank cover switch (R)
Ink tank cover switch (L)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
Carriage HP sensor
Pressure release switch
Media sensor
(Not Used)
(Not Used)
(Not Used)
Media take-up unit detection
Media take-up sensor input signal
Valve open/closed detection sensor (L)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
(Not Used)
Flexible cable connection detection
(J3501, J3502, J3601, J3602)
(Not Used)
(Not Used)
(Not Used)
LCD display contents
0: Sensor ON, 1: Sensor OFF
0: Sensor ON, 1: Sensor OFF
0: Sensor ON, 1: Sensor OFF
0: Sensor ON, 1: Sensor OFF
-
0: Sensor ON, 1: Sensor OFF
0: Sensor ON, 1: Sensor OFF
0: Cover open, 1: Cover close
0: Cover open, 1: Cover close
0: Cover open, 1: Cover close
0: Cover open, 1: Cover close
-
-
-
-
-
-
-
-
-
-
0: Sensor ON, 1: Sensor OFF
0: Realeased, 1:Pressured
0: No media, 1: Media loaded
-
-
-
0: Undetected, 1: Detected
0: LO, 1: HI
0: Sensor ON, 1: Sensor OFF
-
-
-
-
-
-
-
-
-
-
-
-
-
-
0: Connection, 1: Disconnection
-
-
-
