Canon imagePROGRAF IPF8400 Service Manual page 44

Chapter 1
Setting Item
[Interfac [EOP Timer]
e Setup]
[TCP/IP] [IPv4]
[IPv6]
[NetWare] [NetWare]
[Frame Type]
[Print Service]
[AppleTalk]
[Ethernet [Auto Detect]
Driver]*12
[Comm.Mode]
[Ethernet Type]
[Spanning Tree]
[MAC Address]
[Interface Print]
[Return Defaults]
1-30
Specify the timeout period before cancellation of print jobs that cannot be received by the
printer.
[IPv4 Mode] Choose whether the printer IP address is configured automatically or a static IP address is
entered manually.
[Protocol] [DHCP]/ Specify the protocol used to configure the IP address automatically.
[BOOTP]/
[RARP]
[IPv4 Settings] [IP Address]/ Specify the printer network information when using a static IP address.
[Subnet Mask]/ Enter the IP address assigned to the printer, as well as the network subnet mask and default
[Default G/W] gateway.
[DNS Settings] [DNS Dync Specify whether DNS server registration is updated automatically.
update]
[Pri. DNS Specify the DNS server address.
SrvAddr]/[Sec.
DNS SrvAddr]
[DNS Host Specify the DNS host name.
Name]
[DNS Domain Specify the DNS domain name.
Name]
[IPv6 Support] Set whether to support IPv6 connection.
[IPv6 StlessAddrs] Set whether to use IPv6 stateless address.
[DHCPv6] Set whether to use DHCPv6 setting.
[DNS Settings] [DNS Dync Specify whether DNS server registration is updated automatically.
update]-
[Statefull
Addr]/
[Stateless
Addr]
[Pri. DNS
Specify the DNS server address.
SrvAddr]/[Sec.
DNS SrvAddr]
[DNS Host Specify the DNS host name.
Name]
[DNS Domain Specify the DNS domain name.
Name]
Specify the NetWare protocol. To apply your changes, choose Register Setting.
Specify the frame type to use.
Choose the print service.
Specify whether to use the AppleTalk protocol. To apply your changes, choose Register
Setting.
Specify the communication method. To apply your changes, choose Register Setting.
Choose On for automatic configuration of the LAN communication protocol. Choose Off to
use settings values of Comm.Mode and Ethernet Type.
Choose the LAN communication method.
Choose the LAN transfer rate.
Choose whether spanning-tree packets are supported over the LAN.
Displays the MAC address.
Print the interface settings.
Select [OK] to return the [Interface Setup] settings to factory default.
T-1-15
Description/Instructions
