Canon imagePROGRAF IPF8400 Service Manual page 236

Chapter 7
OUTPUT 5
OUTPUT 6
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
MEMO:
- Displays all "?" if "GAP CALIB" is not performed.
- If the value exceeds 1000, 999 is displayed.
7-18
O U T P U T 5
X X X X X X X X X
26 26 26 27 27 27 28 28 28
O U T P U T 6
X X X X X X X X X
31 31 31 32 32 32 33 33 33
Display
position
Media edge (diffuse reflection) media output (including outside light)
Media edge (diffuse reflection) outside light output (when LED is OFF)
Media edge (diffuse reflection) platen output (excluding outside light)
Media edge (diffuse reflection) gain
Media edge (diffuse reflection) current value (Unit: X10mA)
Media edge (regular reflection) media output (including outside light)
Media edge (regular reflection) outside light output (when LED is OFF)
Media edge (regular reflection) platen output (excluding outside light)
Media edge (regular reflection) gain
Media edge (regular reflection) current value (Unit: X10mA)
GAP_Far media output (including outside light)
GAP_Far outside light output (when LED is OFF)
GAP_Far platen output (excluding outside light)
GAP_Far gain
GAP_Far current value (Unit: X10mA)
GAP_Near media output (including outside light)
GAP_Near outside light output (when LED is OFF)
GAP_Near platen output (excluding outside light)
GAP_Near gain
GAP_Near current value (Unit: X10mA)
Density (red) media output (including outside light)
Density (red) outside light output (when LED is OFF)
Density (red) platen output (excluding outside light)
Density (red) gain
Density (red) current value (Unit: X10mA)
Density (green) media output
Density (green) outside light output (including outside light)
Density (green) platen output (excluding outside light)
Density (green) gain
Density (green) current value (Unit: X10mA)
Density (blue) media output (including outside light)
Density (blue) outside light output (when LED is OFF)
Density (blue) platen output (excluding outside light)
Density (blue) gain
Density (blue) current value (Unit: X10mA)
X X X X X X
29 29 29 30 30 30
F-7-15
X X X X X X
34 34 34 35 35 35
F-7-16
Description
