Canon imagePROGRAF IPF8400 Service Manual page 189

J3502
Pin Number Signal name
3 OUT_ENB
4 H0-D-HE-7_B
5 GND
6 H0-D-DATA-7-EV_B
7 GND
8 H0-D-DATA-6-EV_B
9 GND
10 H0-D-DATA-6-OD_B
11 GND
12 H0-D-HE-6_B
13 GND
14 H0-C-HE-5_B
15 GND
16 H0-C-DATA-5-OD_B
17 GND
18 H0-DSOUT2
19 GND
20 H0-DSOUT1
21 GND
22 H0-DLD_LICC2
23 H0-DATA_LICC2
24 H0-DASLK_LICC2
25 GND
26 H0_CLK_B
27 GND
28 H0_LT_B
29 GND
30 H0-C-DATA-5-EV_B
31 GND
32 LIFT_CAM_IN
33 GND
34 H0-B-HE-3_B
35 GND
36 H0-C-DATA-4-EV_B
37 GND
38 H0-B-DATA-3-EV_B
39 GND
40 H0-B-DATA-2-EV_B
41 GND
42 H0-A-DATA-1-EV_B
43 GND
44 H0-A-HE-1_B
45 GND
46 H0-A-DATA-0-EV_B
47 GND
48 VH_CHARGE0
49 VH_CHARGE1
50 GND
J3601
Pin Number Signal name
1 GND
2 ENCODER_B
3 ENCODER_A
4 /CR_COVER
5 GND
6 H-DASH_LICC2_B
7 GND
8 H1-D-DATA-7-OD_B
9 GND
10 /H1-E-HE-8_B
11 GND
IN/OUT Function
OUT Head data enable signal
OUT Head(R) heat enable signal 7(D)
- GND
OUT Even head(R) data signal 7(D)
- GND
OUT Even head(R) data signal 6(D)
- GND
OUT Odd head(R) data signal 6(D)
- GND
OUT Head(R) heat enable signal 6(D)
- GND
OUT Head(R) heat enable signal 5(C)
- GND
OUT Odd head(R) data signal 5(C)
- GND
OUT Head(R) temperature output signal 2
- GND
OUT Head(R) temperature output signal 1
- GND
OUT Head(R) analogue switch latch signal
OUT Head(R) analogue switch data signal
OUT Head(R) analogue switch clock signal
- GND
OUT Head(R) clock signal
- GND
OUT Head(R) latch signal
- GND
OUT Even head(R) data signal 5(C)
- GND
IN Lift cam sensor output signal
- GND
OUT Head(R) heat enable signal 3(B)
- GND
OUT Even head(R) data signal 4(C)
- GND
OUT Even head(R) data signal 3(B)
- GND
OUT Even head(R) data signal 2(B)
- GND
OUT Even head(R) data signal 1(A)
- GND
OUT Head(R) heat enable signal 1(A)
- GND
OUT Even head(R) data signal 0(A)
- GND
OUT VH leakage detection ON/OFF signal 0
OUT VH leakage detection ON/OFF signal 1
- GND
T-6-22
IN/OUT Function
- GND
IN Carriage encoder output signal B
IN Carriage encoder output signal A
IN Carriage cover sensor output signal
- GND
OUT Head analogue switch A/D trigger signal
- GND
OUT Odd head(R) data signal 7(D)
- GND
OUT Head(R) heat enable signal 8(E)
- GND
