Canon imagePROGRAF IPF8400 Service Manual page 188

Chapter 6
J3401
Pin Number Signal name
24 VMGND
25 VMGND
J3501
Pin Number Signal name
1 GND
2 H1-C-DATA-4-OD_OUT
3 GND
4 H1-A-DATA-1-OD_OUT
5 GND
6 H1-B-HE-2_B
7 GND
8 H0-D-DATA-7-OD_B
9 GND
10 H0-E-HE-8_B
11 GND
12 H0-E-DATA-8-OD_B
13 GND
14 H0-F-DATA-10-OD
15 GND
16 H0-E-DATA-9-OD_B
17 GND
18 H0-F-HE-10_B
19 GND
20 H0-F-DATA-11-OD
21 GND
22 H0-F-HE-11_B
23 GND
24 H0-F-DATA-11-EV_B
25 GND
26 H0-F-DATA-10-EV_B
27 GND
28 H0-E-HE-9_B
29 GND
30 H0-E-DATA-9-EV_B
31 GND
32 H-DASH_LICC2_B
33 GND
34 H0-A-DATA-0-OD_B
35 GND
36 H0-A-DATA-1-OD_B
37 GND
38 H0-B-HE-2_B
39 GND
40 H0-B-DATA-2-OD_B
41 GND
42 H0-B-DATA-3-OD_B
43 GND
44 H0-C-HE-4_B
45 GND
46 H0-C-DATA-4-OD_B
47 GND
48 H0-A-HE-0_B
49 GND
50 VHT_MONI
J3502
Pin Number Signal name
1 GND
2 H0-E-DATA-8-EV_B
6-8
IN/OUT Function
- GND
- GND
T-6-20
IN/OUT Function
- GND
OUT Odd head(L) data signal 4(C)
- GND
OUT Odd head(L) data signal 1(A)
- GND
OUT Head(L) heat enable signal 2(B)
- GND
OUT Odd head(R) data signal 7(D)
- GND
OUT Head(R) heat enable signal 8(E)
- GND
OUT Odd head(R) data signal 8(E)
- GND
OUT Odd head(R) data signal 10(F)
- GND
OUT Odd head(R) data signal 9(E)
- GND
OUT Head(R) heat enable signal 10(F)
- GND
OUT Odd head(R) data signal 11(F)
- GND
OUT Head(R) heat enable signal 11(F)
- GND
OUT Even head(R) data signal 11(F)
- GND
OUT Even head(R) data signal 10(F)
- GND
OUT Head(R) heat enable signal 9(E)
- GND
OUT Even head(R) data signal 9(E)
- GND
OUT Head analogue switch A/D trigger signal
- GND
OUT Odd head(R) data signal 0(A)
- GND
OUT Odd head(R) data signal 1(A)
- GND
OUT Head(R) heat enable signal 2(B)
- GND
OUT Odd head(R) data signal 2(B)
- GND
OUT Odd head(R) data signal 3(B)
- GND
OUT Head(R) heat enable signal 4(C)
- GND
OUT Odd head(R) data signal 4(C)
- GND
OUT Head(R) heat enable signal 0(A)
- GND
IN VHT controll signal
T-6-21
IN/OUT Function
- GND
OUT Even head(R) data signal 8(E)
