Canon imagePROGRAF IPF8400 Service Manual page 208

Chapter 6
J602
Pin Number Signal name
43 H0-F-DATA-11-EV
44 H0-E-DATA-8-EV
45 H0-D-DATA-6-EV
46 H0-C-DIA2
47 H0-C-DATA-5-EV
48 H0-B-DIA1
49 H0-A-HE-0
50 H0-B-DATA-2-OD
51 H0-B-DATA-3-OD
52 H0-C-DATA-4-OD
53 GND
54 GND
55 GND
56 H0-F-DATA-11-OD
57 H0-E-DATA-9-EV
58 GND
59 H0-D-DATA-6-OD
60 H0-C-HE-5
61 H0-B-HE-3
62 H0-A-DIA1
63 H0-A-DATA-1-OD
64 GND
65 GND
66 GND
67 GND
68 H0-F-DATA-10-OD
69 H0-F-DIA1
70 H0-D-HE-7
71 GND
72 H0_CLK
73 H0_LT
74 H0-B-DATA-2-EV
75 H0-A-DATA-0-OD
76 GND
77 GND
78 GND
6-28
IN/OUT Function
OUT Even head(R) data signal 11(F)
OUT Even head(R) data signal 8(E)
OUT Even head(R) data signal 6(D)
IN Head(R) DI sensor signal 2(C)
OUT Even head(R) data signal 5(C)
IN Head(R) DI sensor signal 1(B)
OUT Head(R) heat enable signal 0(A)
OUT Odd head(R) data signal 2(B)
OUT Odd head(R) data signal 3(B)
OUT Odd head(R) data signal 4(C)
- GND
- GND
- GND
OUT Odd head(R) data signal 11(F)
OUT Even head(R) data signal 9(E)
- GND
OUT Odd head(R) data signal 6(D)
OUT Head(R) heat enable signal 5(C)
OUT Head(R) heat enable signal 3(B)
IN Head(R) DI sensor signal 1(A)
OUT Odd head(R) data signal 1(A)
- GND
- GND
- GND
- GND
OUT Odd head(R) data signal 10(F)
IN Head(R) DI sensor signal 1(F)
OUT Head(R) heat enable signal 7(D)
- GND
OUT Head(R) clock signal
OUT Head(R) latch signal
OUT Even head(R) data signal 2(B)
OUT Odd head(R) data signal 0(A)
- GND
- GND
- GND
