Canon imagePROGRAF IPF8400 Service Manual page 258

Chapter 7
Print item
JAM 01 to 05
1
2
3
4
5
6
7
8
9
10
11
12
13
INK CHK PC, C, MBK, Y,
M, PM, R, G, B,
PGY, GY, BK
7-40
Print content
JAM log (5 records)
Jam type
Media format
Jam timing
Width detection OFF mode
Head height
(Not Used)
Cut mode
Media passing environment
Borderless/Bordered
(Not Used)
Print mode label No.
Media width
Media type
Refill log
Print whether disable remaining ink detection was
previously set
Printed value
Number: Lowest is the most recent
Date: mm/dd
Time: mm/ss
Jam code
1: CR error
2: Jam
3: Feed failure (delay)
4: Cut failure
*: Unknown
1: Roll media
2: Cut sheet (manual feed from top)
3: Cut sheet (manual feed from front)
4: Cassette
*: Unknown
1: Feed
2: Print
3: Eject
*: Unknown
1: ON
2: OFF
*: Unknown
0: SL (1.2mm)
1: L (1.4mm)
2: M1 (1.8mm)
3: M2 (2.0mm)
4: M3 (2.2mm)
5: H (2.6mm)
*: Unknown
1: User cut
2: Eject cut
3: Auto cut
*: Unknown
0: A(temperature 15 to 25 degrees centigrade/humidity
40 to 60%)
1: B(temperature 25 to 30 degrees centigrade/humidity
40 to 60%)
2: C(temperature 15 to 30 degrees centigrade/humidity
10 to 40%)
3: D(temperature 15 to 30 degrees centigrade/humidity
60 to 80%)
4: E(temperature 15 to 30 degrees centigrade/humidity 0
to 10%, or 15 degrees centigrade or less and 30 degrees
centigrade or more/humidity 0 to 50%[low humidity is
out of guarantee.])
5: F(temperature 15 to 30 degrees centigrade/humidity
80 to 100%, or 15 degrees centigrade or less and 30
degrees centigrade or more/humidity 50 to 100%[high
humidity is out of guarantee.])
*: Unknown
1: Bordered printing
2: Borderless printing
*: Unknown
Display print mode
*: Unknown
Display media width (Unit: mm)
*: Unknown
Display media name
*: Unknown
0: Disable remaining ink detection was never set
1: Disable remaining ink detection was set at least once
