Display message
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink
tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
Ink insufficient.
Press OK and replace ink tank.
No ink tank loaded.
Press OK and check ink tank.
! Do not pull out ink tank.
(Change to the following message)
! Do not use removed ink tanks in other
printers.
No ink tank loaded.
Press OK and check ink tank.
! Do not pull out ink tank.
(Change to the following message)
! Do not use removed ink tanks in other
printers.
No ink tank loaded.
Press OK and check ink tank.
! Do not pull out ink tank.
(Change to the following message)
! Do not use removed ink tanks in other
printers.
No ink tank loaded.
Press OK and check ink tank.
! Do not pull out ink tank.
(Change to the following message)
! Do not use removed ink tanks in other
printers.
No ink tank loaded.
Press OK and check ink tank.
No ink tank loaded.
Press OK and check ink tank.
No ink tank loaded.
Press OK and check ink tank.
Code* Condition detected
03810205-2588 Low on the GY ink tank (as during
cleaning)
03810205-2598 Low on the GY ink tank (during pre-
printing checks)
03810206-2586 Low on the MBK ink tank (as during
cleaning)
03810206-2587 Low on the MBK2 ink tank (as during
cleaning)
03810206-2596 Low on the MBK ink tank (during pre-
printing checks)
03810206-2597 Low on the MBK2 ink tank (during pre-
printing checks)
03810207-258A Low on the R ink tank (as during cleaning) Replace with a fully replenished R ink tank.
03810207-259A Low on the R ink tank (during pre-printing
checks)
03810208-258C Low on the G ink tank (as during cleaning) Replace with a fully replenished G ink tank.
03810208-259C Low on the G ink tank (during pre-printing
checks)
03810209-258B Low on the B ink tank (as during cleaning) Replace with a fully replenished B ink tank.
03810209-259B Low on the B ink tank (during pre-printing
checks)
03810212-2584 Low on the PM ink tank (as during
cleaning)
03810212-2594 Low on the PM ink tank (during pre-
printing checks)
03810213-2585 Low on the PC ink tank (as during
cleaning)
03810213-2595 Low on the PC ink tank (during pre-
printing checks)
03810215-2589 Low on the PGY ink tank (as during
cleaning)
03810215-2599 Low on the PGY ink tank (during pre-
printing checks)
03830101-2521 Y ink tank not installed.
03830101-25AC Y ink tank detachment (when using the
refill ink tank)
03830102-2522 M ink tank not installed.
03830102-25AB M ink tank detachment (when using the
refill ink tank)
03830103-2523 C ink tank not installed.
03830103-25AA C ink tank detachment (when using the
refill ink tank)
03830104-2520 BK ink tank not installed.
03830104-25A9 BK ink tank detachment (when using the
refill ink tank)
03830105-2528 GY ink tank not installed.
03830106-2526 MBK ink tank not installed.
03830106-2527 MBK2 ink tank not installed.
Action
Replace with a fully replenished GY ink tank.
Replace with a fully replenished GY ink tank.
Replace with a fully replenished MBK ink tank.
Replace with a fully replenished MBK ink tank.
Replace with a fully replenished MBK ink tank.
Replace with a fully replenished MBK ink tank.
Replace with a fully replenished R ink tank.
Replace with a fully replenished G ink tank.
Replace with a fully replenished B ink tank.
Replace with a fully replenished PM ink tank.
Replace with a fully replenished PM ink tank.
Replace with a fully replenished PC ink tank.
Replace with a fully replenished PC ink tank.
Replace with a fully replenished PGY ink tank.
Replace with a fully replenished PGY ink tank.
Install a Y ink tank.
Install the detached ink tank.
Install a M ink tank.
Install the detached ink tank.
Install a C ink tank.
Install the detached ink tank.
Install a BK ink tank.
Install the detached ink tank.
Install a GY ink tank.
Install a MBK ink tank.
Install a MBK ink tank.
Chapter 8
8-13
