Canon imagePROGRAF IPF8400 Service Manual page 263

Print item
COUNTER MEDIA 1-7 NAME
TTL
ROLL
CUTSHEET
MEDIA NAME
OTHER
TTL
ROLL
CUTSHEET
MEDIA 44-60
SIZE1 ROLL
P-SQ/P-CNT
36-44
24-36
17-24
0-17
MEDIA 44-60
SIZE2 ROLL
D-SQ/D-CNT
36-44
24-36
17-24
0-17
MEDIA 44-60
SIZE1 CUT P-
SQ/P-CNT
36-44
24-36
17-24
0-17
MEDIA 44-60
SIZE2 CUT
D-SQ/D-CNT
36-44
24-36
17-24
0-17
HEAD DOT PC, C, MBK, Y,
CNT.1 M, PM, R, G, B,
PGY, GY, BK
TTL
HEAD DOT PC, C, MBK, Y,
CNT.2 M, PM, R, G, B,
PGY, GY, BK
TTL
Print content
Media type
Total amount of cumulative print area of roll media and cut
sheet
Cumulative print area of roll media
Cumulative print area of cut sheet
OTHER
Total amount of cumulative print area of roll media and cut
sheet
Cumulative print area of roll media
Cumulative print area of cut sheet
Cumulative print area of roll media equal to or larger than 44
inches but less than 60 inches (physical size)
Cumulative print area of roll media equal to or larger than 36
inches but less than 44 inches (physical size)
Cumulative print area of roll media equal to or larger than 24
inches but less than 36 inches (physical size)
Cumulative print area of roll media equal to or larger than 17
inches but less than 24 inches (physical size)
Cumulative print area of roll media less than 17 inches
(physical size)
Cumulative print area of roll media equal to or larger than 44
inches but less than 60 inches (data size)
Cumulative print area of roll media equal to or larger than 36
inches but less than 44 inches (data size)
Cumulative print area of roll media equal to or larger than 24
inches but less than 36 inches (data size)
Cumulative print area of roll media equal to or larger than 17
inches but less than 24 inches (data size)
Cumulative print area of roll media less than 17 inches (data
size)
Cumulative print area of cut sheet equal to or larger than 44
inches but less than 60 inches (physical size)
Cumulative print area of cut sheet equal to or larger than 36
inches but less than 44 inches (physical size)
Cumulative print area of cut sheet equal to or larger than 24
inches but less than 36 inches (physical size)
Cumulative print area of cut sheet equal to or larger than 17
inches but less than 24 inches (physical size)
Cumulative print area of cut sheet less than 17 inches
(physical size)
Cumulative print area of cut sheet equal to or larger than 44
inches but less than 60 inches (data size)
Cumulative print area of cut sheet equal to or larger than 36
inches but less than 44 inches (data size)
Cumulative print area of cut sheet equal to or larger than 24
inches but less than 36 inches (data size)
Cumulative print area of cut sheet equal to or larger than 17
inches but less than 24 inches (data size)
Cumulative print area of cut sheet less than 17 inches (data
size)
Dot counts of each colors of the currently installed printhead Unit: (x 1,000,000) dots
Total dot counts of each colors of the currently installed
printhead
Cumulative dot counts of each colors
Total cumulative dot counts of each colors
Printed value
Unit: square/meter, square/feet
OTHER
Unit: square/meter, square/feet
Unit: square/meter, square/feet, sheets
(equivalent of A4)
Unit: square/meter, square/feet, sheets
(equivalent of A4)
Unit: square/meter, square/feet, sheets
(equivalent of A4)
Unit: square/meter, square/feet, sheets
(equivalent of A4)
Unit: (x 1,000,000) dots
Chapter 7
7-45
