Canon imagePROGRAF IPF8400 Service Manual page 195

J104
Pin Number Signal name
33 H0-F-HE-10_B
34 GND
35 H0-E-DATA-9-OD_B
36 GND
37 H0-F-DATA-10-OD
38 GND
39 H0-E-DATA-8-OD_B
40 GND
41 H0-E-HE-8_B
42 GND
43 H0-D-DATA-7-OD_B
44 GND
45 H1-B-HE-2_B
46 GND
47 H1-A-DATA-1-OD_OUT
48 GND
49 H1-C-DATA-4-OD_OUT
50 GND
J105
Pin Number Signal name
1 GND
2 VH_CHARGE1
3 VH_CHARGE0
4 GND
5 H0-A-DATA-0-EV_B
6 GND
7 H0-A-HE-1_B
8 GND
9 H0-A-DATA-1-EV_B
10 GND
11 H0-B-DATA-2-EV_B
12 GND
13 H0-B-DATA-3-EV_B
14 GND
15 H0-C-DATA-4-EV_B
16 GND
17 H0-B-HE-3_B
18 GND
19 LIFT_CAM_IN
20 GND
21 H0-C-DATA-5-EV_B
22 GND
23 H0_LT_B
24 GND
25 H0_CLK_B
26 GND
27 H0-DASLK_LICC2
28 H0-DATA_LICC2
29 H0-DLD_LICC2
30 GND
31 H0-DSOUT1
32 GND
33 H0-DSOUT2
34 GND
35 H0-C-DATA-5-OD_B
36 GND
37 H0-C-HE-5_B
38 GND
39 H0-D-HE-6_B
40 GND
41 H0-D-DATA-6-OD_B
IN/OUT Function
OUT Head(R) heat enable signal 10(F)
- GND
OUT Odd head(R) data signal 9(E)
- GND
OUT Odd head(R) data signal 10(F)
- GND
OUT Odd head(R) data signal 8(E)
- GND
OUT Head(R) heat enable signal 8(E)
- GND
OUT Odd head(R) data signal 7(D)
- GND
OUT Head(L) heat enable signal 2(B)
- GND
OUT Odd head(L) data signal 1(A)
- GND
OUT Odd head(L) data signal 4(C)
- GND
T-6-28
IN/OUT Function
- GND
OUT VH leakage detection ON/OFF signal 1
OUT VH leakage detection ON/OFF signal 0
- GND
OUT Even head(R) data signal 0(A)
- GND
OUT Head(R) heat enable signal 1(A)
- GND
OUT Even head(R) data signal 1(A)
- GND
OUT Even head(R) data signal 2(B)
- GND
OUT Even head(R) data signal 3(B)
- GND
OUT Even head(R) data signal 4(C)
- GND
OUT Head(R) heat enable signal 3(B)
- GND
IN Lift cam sensor output signal
- GND
OUT Even head(R) data signal 5(C)
- GND
OUT Head(R) latch signal
- GND
OUT Head(R) clock signal
- GND
OUT Head(R) analogue switch clock signal
OUT Head(R) analogue switch data signal
OUT Head(R) analogue switch latch signal
- GND
OUT Head(R) temperature output signal 1
- GND
OUT Head(R) temperature output signal 2
- GND
OUT Odd head(R) data signal 5(C)
- GND
OUT Head(R) heat enable signal 5(C)
- GND
OUT Head(R) heat enable signal 6(D)
- GND
OUT Odd head(R) data signal 6(D)
Chapter 6
6-15
