Canon imagePROGRAF IPF8400 Service Manual page 45

Setting Item
[System Setup] [Sleep Timer]
[Shut Down Timer]
[Buzzer]
[Contrast Adj.]
[Date & Time] [Date]
[Time]
[Date Format]
[Language]
[Time Zone]
[Length Unit]
[Detect Mismatch]
[Paper Size [Sht Selection 1] Select which size is to be recognized, [ISO A3+] or [13"x19"(Super B)], when the detected size
Basis]
[Sht Selection 2] Select which size is to be recognized, [ISO B1] or [28"x40"(ANSI F)], when the detected size
[Keep Paper Size]
[Rep.P.head Print]
[Nozzle Check]
[Use RemoteUI]
[Reset PaprSetngs]
T-1-16
Description/Instructions
Specify the period before the printer enters Sleep mode.
Specify the period before the printer shuts down.
Set the buzzer. Choose On for the buzzer to sound once for warnings and three times for errors.
Adjust the Display Screen contrast level.
Set the current date.
Set the current time. This can be set only when [Date] is set.
Specify the date format.
Specify the language used on the Display Screen.
Specify the time zone. Time zone options indicate a main city in this time zone and the
difference from Greenwich Mean Time.
Choose the unit of measurement when roll length is displayed. You can switch the unit
displayed for the remaining paper amount.
Set the printing behavior when the paper type and size set with the printer menu does not match
the paper type and size set with the printer driver.
Select [Pause] to pause printing. Select [Warning] to print a warning and continue printing.
Select [None] to continue printing without displaying a warning. Select [Hold Job] to queue the
job with different paper type and size in a job queue on the hard disk.
of the cut sheet is between these sizes.
of the cut sheet is between these sizes.
Select [On] to give priority to paper size. If the margin set with the printer driver is less than
the margin set with the printer menu, the margin set with the printer menu has priority and text
and images extending beyond the margins are truncated.
Select [Off] to give priority to margin settings. If the margins set with the printer driver and the
margins set with the printer menu are different, the larger settings are used for printing.
Select [On] to automatically perform [Adjust Detail] after replacing the Printhead.
Set with [Frequency] the timing to check for nozzle clogging after printing. Select [Standard]
to adjust the checking timing according to the nozzle usage.
Select [1 page] to check after each page.
Select [On] for [Warning] to display a warning when the print head nozzle is clogged while
printing.
Select [Off] to disable access from RemoteUI and enable setting only from the operation panel.
Restores settings that you have changed with Media Configuration Tool to the factory default
values.
Chapter 1
1-31
