Canon imagePROGRAF IPF8400 Service Manual page 241

8) INK-USE2: Counters related to ink consumption
INK-USE2(XX)
INK-USE2(TTL)
N-INK-USE2(XX)
N-INK-USE2(TTL)
9) INK-EXC: Counters related to ink tank replacement
INK-EXC(XX)
INK-EXC(TTL)
N-INK-EXC(XX)
N-INK-EXC(TTL)
10) MEDIA x (x: 1 to 7): Counters related to media
One to seven media types are displayed individually in order with large cumulative print area.
11) MEDIA OTHER: Counters related to media
Displays the total amount of cumulative print area of the other media type than the above-mentioned.
12) MEDIASIZE1 ROLL: Counters related to roll media printing
Display
P-SQ 44-60
P-SQ 36-44
P-SQ 24-36
P-SQ 17-24
P-SQ -17
P-CNT 44-60
P-CNT 36-44
P-CNT 24-36
P-CNT 17-24
P-CNT -17
Display
XX: Ink color
Consumption amount of generic ink of the currently installed ink tank.
Total consumption amount of generic ink of the currently installed ink tanks
XX: Ink color
Consumption amount of refilled ink of the currently installed ink tank
Total consumption amount of refilled ink of the currently installed ink tanks
Display
XX: Ink color
Cumulative count of generic ink tank replacement
Total amount of cumulative count of generic ink tank replacement
XX: Ink color
Cumulative count of refilled ink tank replacement
Total amount of cumulative count of refilled ink tank replacement
Display
NAME Media type
TTL Total amount of cumulative print area of roll media and cut sheet (metric) Sq.m
TTL Total amount of cumulative print area of roll media and cut sheet (inch) Sq.f
ROLL Cumulative print area of roll media (metric)
ROLL Cumulative print area of roll media (inch)
CUT SHEET Cumulative print area of cut sheet (metric)
CUT SHEET Cumulative print area of cut sheet (inch)
Display
NAME Media type
TTL Total amount of cumulative print area of roll media and cut sheet (metric) Sq.m
TTL Total amount of cumulative print area of roll media and cut sheet (inch) Sq.f
ROLL Cumulative print area of roll media (metric)
ROLL Cumulative print area of roll media (inch)
CUT SHEET Cumulative print area of cut sheet (metric)
CUT SHEET Cumulative print area of cut sheet (inch)
Cumulative print area of paper equal to or larger than 44 inches but less than 60 inches (physical size)
Cumulative print area of paper equal to or larger than 36 inches but less than 44 inches (physical size)
Cumulative print area of paper equal to or larger than 24 inches but less than 36 inches (physical size)
Cumulative print area of paper equal to or larger than 17 inches but less than 24 inches (physical size)
Cumulative print area of paper less than 17 inches (physical size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 44 inches but less than 60 inches
(physical size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 36 inches but less than 44 inches
(physical size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 24 inches but less than 36 inches
(physical size)
Cumulative number of sheets of A4-equivalent paper equal to or larger than 17 inches but less than 24 inches
(physical size)
Cumulative number of sheets of A4-equivalent paper less than 17 inches (physical size)
Description
Description
Description
Description
Description
Chapter 7
Unit
ml
ml
ml
ml
Unit
ml
ml
ml
ml
Unit
-
Sq.m
Sq.f
Sq.m
Sq.f
Unit
-
Sq.m
Sq.f
Sq.m
Sq.f
Unit
m2/Sq.f
m2/Sq.f
m2/Sq.f
m2/Sq.f
m2/Sq.f
sheets
sheets
sheets
sheets
sheets
7-23
