Canon imagePROGRAF IPF8400 Service Manual page 191

J3602
Pin Number Signal name
21 GND
22 H1-C-DATA-5-OD_B
23 GND
24 H1_CLK
25 GND
26 /H1_LT_B
27 GND
28 H1-C-DATA-5-EV_B
29 GND
30 /H1-B-HE-3_B
31 GND
32 H1-C-DATA-4-EV_B
33 GND
34 H1-B-DATA-3-EV_B
35 GND
36 H1-B-DATA-2-EV_B
37 GND
38 H1-A-DATA-1-EV_B
39 GND
40 /H1-A-HE-1_B
41 GND
42 H1-A-DATA-0-EV_B
43 GND
44 /H1-A-HE-0_B
45 GND
46 H1-A-DATA-0-OD_B
47 GND
48 VHT_ENB
49 HV_ENB
50 FFC_SLANT_DET_SNS
IN/OUT Function
- GND
OUT Odd head(L) data signal 5(C)
- GND
OUT Head(L) clock signal
- GND
OUT Head(L) latch signal
- GND
OUT Even head(L) data signal 5(C)
- GND
OUT Head(L) heat enable signal 3(B)
- GND
OUT Even head(L) data signal 4(C)
- GND
OUT Even head(L) data signal 3(B)
- GND
OUT Even head(L) data signal 2(B)
- GND
OUT Even head(L) data signal 1(A)
- GND
OUT Head(L) heat enable signal 1(A)
- GND
OUT Even head(L) data signal 0(A)
- GND
OUT Head(L) heat enable signal 0(A)
- GND
OUT Odd head(L) data signal 0(A)
- GND
OUT VHT enable signal
OUT HV enable signal
- -
Chapter 6
6-11
