Appendix A — Examples
A-5

LabVIEW™

This example shows how to read the trace data from the instrument in 32-bit integer format.
The output is an array of data point magnitudes. Figure 1 shows the data capture and
conversion to 32-bit integers in the format used by LabVIEW. Figure 2 shows the details of
the conversion.
Your instrument must first be defined to the VISA resource manager using
Note NI-MAX. The VISA resource for your instrument serves as the VISA resource input
to the vi.
