Chapter 4 — Cable & Antenna Analyzer Mode Commands

:CALCulate:TRANsform:DISTance:WINDow

RECTangular|MSLobe|NSLobe|LSLobe
:CALCulate:TRANsform:DISTance:WINDow?
Cmd Description: Command sets the window type for time domain.
Query Description: Query returns the window type for time domain.
Param Type: Character
Param Range: RECTangular|MSLobe|NSLobe|LSLobe
Default Value: NSLobe
Example: To set time domain window type to rectangular:

:CAPTure:STARt

Cmd Description: Command starts the data capture for continuous sweeps. It does not
Example: To start data capture

:CAPTure:STOP

Cmd Description: Command stops the data capture for continuous sweeps. It does not
Example: To stop capture:

:CAPTure:TRACe#:DATA? FDATa|SDATa|FMEM|SMEM

Cmd Description: Command is used to return the data block of the specified trace at the
Example: To trigger a sweep:
S331L PM
:CALC:TRAN:DIST:WIND RECT
work in single sweep and hold mode.
:CAPT:STAR
work in single sweep and hold mode.
:CAPT:STOP
end of a sweep, while the instrument is in continuous sweep mode. This
command must follow the :CAPTure:STARt command. A
:CAPTure:STOP command is used to end the capture session. If the
system is in single sweep and hold mode, then this command is ignored.
:CAPT:TRAC1:DATA? FDAT
PN: 10580-00322 Rev. F 4-17
