Chapter 4 — Cable & Antenna Analyzer Mode Commands

:CALCulate:MARKer#:PEAK:BOUNded

Cmd Description: This command sets specified marker to the trace peak value between
Example: To set marker 5 to the peak between markers 1 and 2:
Notes: Replace '#' with the required marker number. Check User Guide for the

:CALCulate:MARKer#:TRACking

PEAK|VALLey|BNDPeak|BNDValley|OFF
:CALCulate:MARKer#:TRACking?
Cmd Description: Command sets the tracking mode of the specified marker.
Query Description: Query returns the tracking mode of the specified marker. Query returns
Param Range: PEAK|VALLey|BNDPeak|BNDValley|OFF
Default Value: OFF
Example: To set marker 2 to peak tracking:
Notes: Replace '#' with the required marker number. Check User Guide for the

:CALCulate:MARKer#:TYPE REFerence|DELTa

:CALCulate:MARKer#:TYPE?

Cmd Description: Command sets the type of the specified marker.
Query Description: Query returns the type of the specified marker. Query returns REF if
Param Range: REFerence|DELTA
Default Value: REF
Example: To set marker 2 type to delta:
Notes: Replace '#' with the required marker number. Check User Guide for the
S331L PM
two markers. Markers 5 and 7 will search for the peak between markers
1 and 2. Markers 6 and 8 will search for the peak between markers 3
and 4.
:CALC:MARK5:PEAK:BOUN
number of supported markers in each mode. If any marker other than 5,
6, 7, or 8 is specified, the bounded marker will be set to 5 by default.
PEAK for peak tracking, or returns VALL for valley tracking, or returns
BNDP for bounded peak tracking, or returns BNDV for bounded valley
tracking.
:CALC:MARK2:TRAC PEAK
number of supported markers in each mode. If any marker other than 5,
6, 7, or 8 is specified, the bounded marker will be set to 5 by default.
the specified marker is a reference marker, or returns DELT if the
specified marker is a delta marker.
:CALC:MARK2:TYPE DELT
number of supported markers in each mode.
PN: 10580-00322 Rev. F 4-11
