Anritsu Site Master S331L Scpi Programming Manual page 6

1-3 Remote Operation Setup and Interface
USB Interface, Type Mini-B
The USB 2.0 Mini-B device connector is used to connect the instrument directly to a
PC. The first time the instrument is connected to a PC, the normal USB device
detection by the computer operating system takes place.
1. Power on the instrument and controller PC and wait for the systems to power up
completely.
2. Connect the USB cable Mini-B connector to the instrument.
3. Connect the USB cable A connector to the controller PC USB host port. The
controller PC should indicate "New Hardware Found" if the combination of USB
VID/PID/Serial Number has never been connected to this controller PC.
Figure 1-1. USB Found New Hardware Wizard
1-2 PN: 10580-00322 Rev. F
Chapter 1 — General Information
S331L PM
