Chapter 4 — Cable & Antenna Analyzer Mode Commands
:CALCulate#:LIMit:LOWer:SEGMent:STARt:X <value>
:CALCulate#:LIMit:LOWer:SEGMent:STARt:X?
Cmd Description: Command sets the lower limit line X start value for current segment.
Query Description: Query returns the lower limit line X start value for active segment.
Param Type: Float
Default Units: Hz for Frequency domain, m or ft for Distance domain, s for Time
Example: To set limit X start value to 1 MHz for trace 1:
Notes: Replace '#' with the required trace number. Check User Guide for the
:CALCulate#:LIMit:LOWer:SEGMent:STARt:Y <amplitude>
:CALCulate#:LIMit:LOWer:SEGMent:STARt:Y?
Cmd Description: Command sets the lower limit line Y start value for active segment.
Query Description: Query returns the lower limit line Y start value for active segment.
Param Type: Float
Default Units: Current active trace y-axis units
Example: To set limit start amplitude to 20 dB for trace 1:
Notes: Replace '#' with the required trace number. Check User Guide for the
:CALCulate#:LIMit:LOWer:SEGMent:STOP:X <value>
:CALCulate#:LIMit:LOWer:SEGMent:STOP:X?
Cmd Description: Command sets the lower limit line X stop value for active segment.
Query Description: Query returns the upper limit line X stop value for active segment.
Param Type: Float
Default Units: Hz for Frequency domain, m or ft for Distance domain, s for Time
Example: To set limit X stop value to 1 MHz for trace 1:
Notes: Replace '#' with the required trace number. Check User Guide for the
S331L PM
domain
:CALC1:LIM:LOW:SEGM:STAR:X 1000000
number of supported traces in each mode.
:CALC1:LIM:LOW:SEGM:STAR:Y 20
number of supported traces in each mode.
Time units are available only if option 2 is installed.
domain
:CALC1:LIM:LOW:SEGM:STOP:X 1000000
number of supported traces in each mode.
PN: 10580-00322 Rev. F
4-3
