MACHINE OVERVIEW

NOTE: The illustration below shows a cab machine. Canopy machines are similar for non-cab related items.
1
17
Fig. 3-1
1) Arm cylinder
2) Boom
3) Boom swing cylinder
4) Cab or canopy
5) Carrier roller
6) Drive sprocket
7) Track rollers
8) Track
9) Track frame
SANY
2
16
15
14
13
12
11
10
Operation and Maintenance Manual — 0120
3
9 8
10) Idler
11) Dozer blade
12) Dozer blade cylinder
13) Boom pivot
14) Boom cylinder
15) Bucket
16) Arm
17) Bucket cylinder
