Machine Controls
NOTE: Keep all the control levers in a neutral
position when moving the hydraulic lockout
control lever to the unlocked (open) position.
Move the hydraulic lockout control lever to the unlocked
(open) position (3) to enable the hydraulic controls.

Directional Arrow

The directional arrow (1) on each of the track frames
indicates forward movement of the machine. Check these
arrows before using the travel control levers/pedals. The
drive sprocket is at the rear of the track frame.
If the track frame is facing backward, the travel direction
will be opposite the maneuvering direction of the travel
control lever/pedal. The machine will move forward when
you pull the control levers backward, and backward when
you push them forward. Left and right control directions
are also reversed when the track frame faces backward.
3-20
Fig. 3-32
Operation and Maintenance Manual — 0120
SY35U Excavator OMM
3
Fig. 3-31
0002982
1
0003794
