MACHINE APPLICATIONS

This cab or canopy excavator is a multipurpose construction machine used primarily for digging or loading earth
and stones. It can also be used for grading, slope-trimming, lifting, breaking, demolishing, and trenching. It can
perform the functions of a bulldozer, loader, and a crane.
This excavator can also operate a variety of optional equipment.
SANY assumes no responsibility for any consequence caused by use outside this specified range.

Machine Directions

In this manual, the front, back, left, and right directions indicate the moving direction when viewed from the
operator seat (see Fig. 1-1).
SANY
6
5
4
Fig. 1-1
1) Front
2) Right
3) Sprocket
Operation and Maintenance Manual — 0120
1
2
3
0003784
4) Back
5) Left
6) Operator seat
