SY35U Excavator OMM
NOTE: Never overfill the fuel tank. Stop fueling if the fuel spills over the fuel fill strainer. Make sure the fuel
nozzle does not damage the fuel fill strainer.
3. Install the fuel filler cap after refueling.

Fuel Tank Filler Cap

NOTICE!
To prevent damage to the fuel filler cap:
• Make sure the O-ring on the fuel filler cap is
clean. If the O-ring is contaminated by dirt or
debris, the O-ring could be damaged and not
seal improperly.
• Inspect the O-ring for wear or damage,
replace as necessary.
Failure to follow this notice could damage the
machine or cause it to operate improperly.
1. To remove the filler cap (1), turn it counterclockwise.
2. To install the filler cap, place the cap on the filler neck and turn it clockwise.
SANY
Fig. 4-6
Operation and Maintenance Manual — 0120
Machine Operation
1
0003772
4-9
