Machine Controls

Function List Screen

Access the Function List screen by pressing the button
under the folder icon on the home screen. See "Home
Screen" on page 3-34.
The Function List screen displays the following:
• Main Menu – Machine operational information
and controls.
NOTE: The Main Menu screen is accessed with a
password. See "System Information Screen"
on page 3-37.
• Operating Mode – Designation of work equipment
and corresponding hydraulic flow control.
• Quick Coupler Control – Not equipped.
• Time calibration – Correct the year, month, day,
time and time zone.
• System unlocked – Factory and service only.
• Reserved function – Not used at this time.
Reserved for future function.
NOTE: Access to some screens requires a password.
1. Press the button below the left/right arrow icon (1) to scroll to and illuminate the selected icon.
2. Press the button below the gear icon (2) to display the system setup screen which is password-protected for use
by SANY only.
3. Press the button below the check-mark icon (3) to confirm the selected icon.
NOTE: To return to the home screen, press the button below the return icon (4).
3-36
Operation and Maintenance Manual — 0120
SY35U Excavator OMM
1 2
Fig. 3-53
4
3
0003823
