SANY SY35U Operation And Maintenance Manual page 145

SY35U Excavator OMM
8. Adjust the boom-arm angle (3) to between 90° and
110° and lower the bucket so that the flat surface is in
contact with the ground. Drive the machine slowly
onto the ramps.
9. Operate the boom and the arm slowly when the
machine is on the ramps. Allow the machine to
descend slowly until it comes in contact with the
ground.
NOTICE!
• Use extreme care when the machine drives over the joint area between the trailer and the
ramps.
• Avoid damage caused by unexpected movement of the work equipment.
• Maintain the boom-arm between an angle of 90° and 110°.
• Avoid unloading the machine with the arm retracted.
Failure to follow this notice could cause damage to the machine or cause it to operate
improperly.
SANY
Fig. 4-77
Fig. 4-78
Operation and Maintenance Manual — 0120
Machine Operation
3
0002949
0002951
4-57
