AutomationDirect DURAPULSE Series User Manual page 77

Parameter
Description
*
Electronic Thermal
P6.00
Overload Relay
P6.01
Auto Restart after Fault
P6.02
Momentary Power Loss
P6.03 Reverse Operation Inhibit
P6.04
Auto Voltage Regulation
P6.05
Over-Voltage Stall Prevention
P6.06
Auto Adjustable Accel/Decel
P6.07
Over-Torque Detection Mode
P6.08
Over-Torque Detection Level
P6.09
Over-Torque Detection Time
Over-Current Stall Prevention
P6.10
during Acceleration
Over-Current Stall Prevention
P6.11
during Operation
Maximum Allowable
P6.12
Power Loss Time
Base-Block Time
P6.13
for Speed Search
Maximum
P6.14
Speed Search Current Level
* Some parameters and settings are available only in later firmware versions of DURA
the beginning of this "DURA
1st Ed. Rev. D 05/2013
Parameter Summary (continued)
Protection Parameters
00: Inverter/Vector Duty Motors
01: Fan Cooled Standard Motors
02: Inactive
00 to 10
00: Stop operation after momentary power
loss
01: Continue operation after momentary
power loss, speed search from Speed
Reference
02: Continue operation after momentary
power loss, speed search from
Minimum Speed
00: Enable Reverse Operation
01: Disable Reverse Operation
00: AVR enabled
01: AVR disabled
02: AVR disabled during decel
03: AVR disabled during stop
00: Enable Over-voltage Stall Prevention
01: Disable Over-voltage Stall Prevention
00: Linear Accel/Decel
01: Auto Accel, Linear Decel
02: Linear Accel, Auto Decel
03: Auto Accel/Decel
04: Auto Accel/Decel Stall Prevention (limited
by P1.01, P1.02, P1.05 and P1.06)
00: Disabled
01: Enabled during constant speed
operation
02: Enabled during acceleration
30 to 200%
0.1 to 10.0
20 to 200%
00: Disable
20 to 200%
0.3 to 5.0 sec
0.3 to 5.0 sec
30 to 200%
Parameter Summary" section for more information.
PULSE
DURA
Chapter 4: AC Drive Parameters
Range*
PULSE
PULSE AC Drive User Manual
Default User
Setting Setting
00
00
00
00
00
00
00
00
150
0.1
150
150
2.0
0.5
150
drives. Refer to
4–9
