AutomationDirect DURAPULSE Series User Manual page 71

Parameter
Description
*
P1.00
Stop Methods
v P1.01
Acceleration Time 1
v P1.02
Deceleration Time 1
P1.03
Accel S-curve
P1.04
Decel S-curve
v P1.05
Acceleration Time 2
v P1.06
Deceleration Time 2
Select method to use
P1.07
2nd Accel/Decel
Accel 1 to Accel 2
P1.08
frequency transition
Decel 2 to Decel 1
P1.09
frequency transition
P1.10
Skip Frequency 1
P1.11
Skip Frequency 2
P1.12
Skip Frequency 3
P1.13
Skip Frequency 4
P1.14
Skip Frequency 5
P1.17
Skip Frequency Band
P1.18
DC Injection Current Level
P1.20
DC Injection during Start-up
P1.21 DC Injection during Stopping
P1.22 Start-point for DC Injection
* Some parameters and settings are available only in later firmware versions of DURA
the beginning of this "DURA
v Parameter can be set during RUN Mode.
1st Ed. Rev. D 05/2013
Parameter Summary
Ramp Parameters
00: Ramp to Stop
01: Coast to Stop
0.1 to 600.0s (must be > 1s to be effective)
0.1 to 600.0s (must be > 1s to be effective)
0 to 7
0 to 7
0.1 to 600.0s (must be > 1s to be effective)
0.1 to 600.0s (must be > 1s to be effective)
00: RMP2 from DI terminal
01: Transition Frequencies P1.08 & P1.09
0.0 to 400.0 Hz
0.0 to 400.0 Hz
0.0 to 400.0 Hz
0.0 to 400.0 Hz
0.0 to 400.0 Hz
0.0 to 400.0 Hz
0.0 to 400.0 Hz
0.0 to 20.0 Hz
00 to 100 %
0.0 to 5.0 sec
0.0 to 25.0 sec
0.0 to 60.0 Hz
Parameter Summary" section for more information.
PULSE
DURA
Chapter 4: AC Drive Parameters
Range*
PULSE
PULSE AC Drive User Manual
Default User
Setting Setting
00
10.0
30.0
00
00
10.0
30.0
00
0.0
0.0
0.0
0.0
0.0
0.0
0.0
0.0
00
0.0
0.0
0.0
drives. Refer to
4–3
