Chapter 5: DURA
DURA Parameter Memory Addresses
PULSE
The octal address also can be used in the WX / RX instruction of the DL-250-1, DL-450,
and DL05.
Parameter
P0.00
Motor Nameplate Voltage
P0.01 Motor Nameplate Amps
P0.02
Motor Base Frequency
P0.03
Motor Base RPM
P0.04 Motor Maximum RPM
P0.05
Motor Auto Tune
P0.06
Motor Line to Line Resistance R1
P0.07 Motor No-Load Current
P1.00
Stop Methods
v P1.01
Acceleration Time 1
v P1.02
Deceleration Time 1
P1.03
Accel S-curve
P1.04
Decel S-curve
v P1.05
Acceleration Time 2
v P1.06
Deceleration Time 2
P1.07
Select method to use - 2nd Accel/Decel
P1.08
Accel 1 to Accel 2 frequency transition
P1.09
Decel 2 to Decel 1 frequency transition
P1.10
Skip Frequency 1
P1.11
Skip Frequency 2
P1.12
Skip Frequency 3
P1.13
Skip Frequency 4
P1.14
Skip Frequency 5
P1.17
Skip Frequency Band
P1.18 DC Injection Current Level
P1.20
DC Injection during Start-up
P1.21
DC Injection during Stopping
P1.22 Start-point for DC Injection
* For Modbus Decimal addresses used with CLICK PLCs,
insert another zero as the next-to-most-significant digit, e.g., 402333 instead of 42333.
v Parameter can be set during RUN Mode.
5–4 DURA
PULSE
PULSE MODBUS Communications
Parameter Memory Addresses
Description
Motor Parameters
Ramp Parameters
AC Drive User Manual
Modbus
Hexadecimal
Decimal *
0000 40001
0001 40002
0002 40003
0003 40004
0004 40005
0005 40006
0006 40007
0007 40008
0100 40257
0101 40258
0102 40259
0103 40260
0104 40261
0105 40262
0106 40263
0107 40264
0108 40265
0109 40266
010A 40267
010B 40268
010C 40269
010D 40270
010E 40271
0111 40274
0112 40275
0114 40277
0115 40278
0116 40279
1st Ed. Rev. D
Octal
0
1
2
3
4
5
6
7
400
401
402
403
404
405
406
407
410
411
412
413
414
415
416
421
422
424
425
426
05/2013
