Line Reactor Dimensions – LR Series (continued)
LR-22P0-1PH, LR-23P0-1PH
Mounting feet with multiple mounting slots allow replacement of most other
reactors using existing mounting holes. Use four bolts to mount the LR reactors.
(Units = inches [mm])
[63.5]
MOUNTING
1st Ed. Rev. D 05/2013
6.00
[152.4]
4.81
[122.2]
4.00
[101.6]
A1
5.00
[127.0]
A2
2.50
[63.5]
12X 0.31
[7.9]
2.50
2.00
[50.8]
MOUNTING
3.20
[81.3]
DURA
Appendix A: Accessories
B1
B2
2.50
[63.5]
3.19
[81.0]
4X Ø0.25
[Ø6.4]
