Chapter 3: Keypad Operation and Quickstart
P2.00
In some applications it is perfectly acceptable to leave this parameter set for
"00" - General Purpose.
P3.00
If parameter P3.00 = 0, 1, or 3, enabling the keypad STOP key, the drive will stop if the
keypad is removed from the drive.
3–12 DURA
PULSE
Volts/Hertz Settings
Range: 00 - General Purpose
01 - High Starting Torque
02 - Fans and Pumps
03 - Custom
The DURA
AC drive has some predefined torque settings that
PULSE
meet the needs of most applications. A custom setting is available if
needed. In this example, the motor will be running a pump.
Source of Operation Command
Settings 00 Operation Determined by Digital Keypad
01 Operation determined by external control
terminals. Keypad STOP is enabled.
02 Operation determined by external control
terminals. Keypad STOP is disabled.
03 Operation determined by RS-485 interface.
Keypad STOP is enabled.
04 Operation determined by RS-485 interface.
Keypad STOP is disabled.
The AC drive operation will be determined by the Digital Keypad.
AC Drive User Manual
Setting: 02
Default Setting: 00
Setting: 00
Default Setting: 00
