AutomationDirect DURAPULSE Series User Manual page 75

Parameter
Description
*
Source of Frequency
P4.00
Command
v P4.01
Analog Input Offset Polarity
v P4.02
Analog Input Offset
v P4.03
Analog Input Gain
Analog Input
P4.04
Reverse Motion Enable
Loss of AI2 Signal
P4.05
(4-20 mA)
v P4.11
Analog Output Signal
v P4.12
Analog Output Gain
2nd Source of
P4.13
Frequency Command
2nd Analog Input
v P4.14
Offset Polarity
v P4.15
2nd Analog Input Offset
v P4.16
2nd Analog Input Gain
v P4.17
Trim Frequency Reference
v P4.18
Trim Mode Select
* Some parameters and settings are available only in later firmware versions of DURA
the beginning of this "DURA
v Parameter can be set during RUN Mode.
1st Ed. Rev. D 05/2013
Parameter Summary (continued)
Analog Parameters
01: Frequency determined by digital keypad
up/down
02: Frequency determined by 0 to +10V
input on AI1 terminal
03: Frequency determined by 4 to 20 mA
input on AI2 terminal
04: Frequency determined by 0 to 20 mA
input on AI2 terminal
05: Frequency determined by RS-485
communication interface
06: Frequency determined by -10V to +10V
input on (AI3) terminal
00: No Offset
01: Positive Offset
02: Negative Offset
0.0 to 100.0%
0.0 to 300.0%
00: Forward Motion Only
01: Reverse Motion Enable
00: Decelerate to 0Hz
01: Stop immediately and display error
code "External Fault"
02: Continue operation by the last
frequency command
00: Frequency Hz
01: Current A
02: PV
00 to 200%
same settings as for P4.00
same settings as for P4.01
0.0 to 100.0%
0.0 to 300.0%
0.0 to 400.0 Hz
00: Disable Trim function
01: 1st source frequency + 2nd source freq
02: 1st source frequency - 2nd source freq
03: Speed Command +
Trim Frequency Reference (P4.17)
04: Speed Command -
Trim Frequency Reference (P4.17)
Parameter Summary" section for more information.
PULSE
DURA
Chapter 4: AC Drive Parameters
Range*
PULSE
PULSE AC Drive User Manual
Default User
Setting Setting
01
00
0.0
100.0
00
00
00
100
06
00
0.0
(float)
100.0
(float)
0.0 (float)
00
drives. Refer to
4–7
