AutomationDirect DURAPULSE Series User Manual page 128

Chapter 4: AC Drive Parameters
Auto Adjustable Accel/Decel
P6.06
Settings:
00
01
02
03
04
If the auto accel/decel is selected, the AC drive will accel/decel in the fastest and
smoothest means possible by automatically adjusting the time of accel/decel.
This parameter provides five modes to choose:
• 00 Linear Acceleration and deceleration (operation by P1.01,
• 01 Automatic acceleration, linear deceleration (Operation by automatic
• 02 Linear acceleration and automatic deceleration (Operation by automatic
• 03 Automatic acceleration, deceleration (Operation by AC drive auto adjustable
• 04 Auto acceleration, deceleration. The auto accel/decel will not be quicker than
Over-Torque Detection Mode
P6.07
Settings:
00
01
02
P6.08 Over-Torque Detection Level
Range: 30 to 200%
• A setting of 100% is proportional to the Rated Output Current of the drive.
• This parameter sets the Over-Torque Detection level in 1% increments. (The AC
drive rated current is equal to 100%.)
Over-Torque Detection Time
P6.09
Range: 0.1 to 10.0
This parameter sets the Over-Torque Detection Time in units of 0.1 seconds.
4–60 DURA
PULSE
Linear Accel/Decel
Auto Accel, Linear Decel
Linear Accel, Auto Decel
Auto Accel/Decel
Auto Accel/Decel Stall Prevention
P1.02 or P1.05, P1.06 acceleration/deceleration time).
acceleration time, P1.02 or P1.06 deceleration time).
acceleration time, P1.01 or P1.05 acceleration time).
control).
the settings for acceleration (P1.01 or P1.05) or deceleration (P1.02 or P1.06).
The operation is specific to preventing a stall.
Disabled
Enabled during constant speed operation
Enabled during acceleration
AC Drive User Manual
Default Setting: 00
Default Setting: 00
Default Setting: 150
Default Setting: 0.1
1st Ed. Rev. D 05/2013
