Dura Pulse - AutomationDirect DURAPULSE Series User Manual

DURA
PULSE
U M
SER ANUAL
R
EVISION
Please include the Manual Number and the Manual Issue, both shown below, when
communicating with Technical Support regarding this publication.
Manual Number:
Issue:
Issue Date:
Issue Date
First Edition 12/08/2003 Original
First Edition,
2/26/2004
Revision A
First Edition,
06/2007
Revision B
First Edition,
06/24/2011
Revision C
First Edition,
05/2013
Revision D
AC D
RIVE
H
ISTORY
GS3-M
First Edition, Revision D
05/2013
Publication History
Description of Changes
Corrected Watt loss information in Chapter One.
Minor changes, corrections, and addtn'l information throughout.
Minor changes and corrections throughout;
Ch4 - New parameters & revised parameter explanations;
Ch5 - New PLC program.
Minor changes and corrections throughout.
Ch2 – Wiring diagram & terminal spec modifications.
Ch4 – Parameter description modifications
(P2.10, P3.11-3.14, P6.00, P6.18, P9.04).
Ch5 – PLC communication cable notes.
AppxA – New accessories: LR-xxxx line reactors; 1-phase EMI filters; 1-phase
fuses & blocks; GS-EDRV100; GS replacement cooling fans.
AppxB – CLICK PLCs & connections.
Minor changes and corrections throughout.
Ch1 – New info for "Selecting the Proper Drive Rating."
Ch2 – Storage conditions, capacitor recharge, and short-circuit information.
Ch3 – Clarification of P4.00 in examples.
Ch4 – New parameter info, especially for firmware v1.05; new analog input
example.
Ch5 – New and revised info regarding parameters, wiring and cabling, and
CLICK and DirectLOGIC PLC programming.
Ch6 – Storage conditions; capacitor recharge info.
AppxA – Fusing and SCCR specs; ZIPLink™ GS cables.
AppxB – New PLC components.
h–1
