Chapter 4: AC Drive Parameters
Multi-Function Input (DI3)
P3.02
P3.03 Multi-Function Input (DI4)
Multi-Function Input (DI5)
P3.04
P3.05 Multi-Function Input (DI6)
Multi-Function Input (DI7)
P3.06
P3.07 Multi-Function Input (DI8)
Multi-Function Input (DI9)
P3.08
P3.09 Multi-Function Input (DI10)
P3.10 Multi-Function Input (DI11)
Settings for P3.02 to P3.10:
00
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
*19
*20
99
* Parameter setting available only with firmware v1.04 or higher (refer to P9.39)
** Use either setting 00 or 01, but not both. Use interposing relays if more contacts
are needed.
*** Accel / Decel times must be more than one second in order for Increase (14)
4–30 DURA
PULSE
**External Fault (N.O.)
**External Fault (N.C.)
External Reset
Multi-Speed Bit 1 / PID Setpoint Bit 1
Multi-Speed Bit 2 / PID Setpoint Bit 2
Multi-Speed Bit 3 / PID Setpoint Bit 3
Multi-Speed Bit 4
Manual Keypad Control
Reserved
Jog
External Base Block (N.O.)
External Base Block (N.C.)
Second Accel/Decel Time
Speed Hold (P4.00 must be set to 01.)
***Increase Speed (P4.00 must be set to 01.)
***Decrease Speed (P4.00 must be set to 01.)
Reset Speed to Zero (P4.00 must be set to 01.)
PID Disable (N.O.)
PID Disable (N.C.)
1st/2nd Source Select (N.O.)
1st/2nd Source Select (N.C.)
Input Disable
and Decrease (15) Speed settings to work efficiently.
AC Drive User Manual
Default Setting: 00
Default Setting: 03
Default Setting: 04
Default Setting: 05
Default Setting: 06
Default Setting: 09
Default Setting: 02
Default Setting: 12
Default Setting: 10
