AutomationDirect DURAPULSE Series User Manual page 57

Source of Frequency Command
P4.00
Settings:
* In order to set P4.00 = 02, you must first change the value of P4.13 to
P6.00 Electronic Thermal Overload Relay
Settings:
This function setting 00 is the standard overload protection curve used
to protect inverter/vector duty motors.
P8.00 User Defined Display Function
Settings:
The AC drive display will default to motor speed (rpm) when running.
1st Ed. Rev. D 05/2013
Chapter 3: Keypad Operation and Quickstart
01 Frequency determined by digital keypad up/down
02* Frequency determined by 0 to +10V input on AI1
terminal.
03 Frequency determined by 4 to 20 mA input on AI2
terminal.
04 Frequency determined by 0 to 20 mA input on AI2
terminal.
05 Frequency determined by RS-485 communication
interface
06 Frequency determined by-10V~+10V input on AI3
terminal
some value other than two (02) in order to avoid the "Error: Duplicate
Function" error message. (P4.13 default value is 02)
00 Constant Torque (inverter/vector duty motor)
01 Variable Torque (fan-cooled standard motor)
02 Inactive
00 Output Frequency (Hz)
01 Motor Speed (RPM)
02 Scaled Frequency
03 Output Current (A)
04 Motor Load (%)
05 Output Voltage(V)
06 DC Bus Voltage (V)
07 PID Setpoint
08 PID Feedback (PV)
09 Frequency Setpoint
DURA
Default Setting: 00
PULSE AC Drive User Manual
Setting: 02
Default: 01
Setting: 00
Default: 00
Setting: 01
3–9
