Appendix B: Using DURA
Typical PLC Connections to DURA
DirectLOGIC Sourcing DC Output Modules
• D0-06DD2
• D0-06DD2-D
• D0-10TD2
• D0-16TD2
• D2-08TD2
DC Voltage Supplied from PLC or external source:
+
+24 VDC
–
Main circuit (power) terminals
Mode switch SW1 needs to be set to the "Source" position when connecting to a
"sourcing" output module.
B–12 DURA
PULSE
AC Drives with AutomationDirect PLCs
PULSE
Sourcing DC Output Module
+V
0
1
2
3
4
5
6
7
10
11
12
COM
AC Drive User Manual
AC Drives (continued)
PULSE
• D2-16TD2-2
• D2-32TD2
• D4-08TD2
• D4-16TD2
• D4-32TD2
GS3-xxxx
+24V Power Source
N/C
(20mA max.)
DI1
Input Mode Setting
Sink
DI2
DI3
Source
DI4
DI5
DI6
DI7
DI8
DI9
DI10
DI11
DCM
Digital Signal Com.
See Power
Wiring Diag.
Control circuit terminal
• T1K-08TD2-1
• T1K-16TD2-1
SW1
6 1
Shielded leads
