Parameter Setup
In order to meet the needs of this application, the parameters should be set as follows:
P0.00 Motor Nameplate Voltage
Range: 230V series: 200/208/220/230/240
This parameter setting is determined by the motor nameplate.
P0.01 Motor Nameplate Amps
Range: Drive Rated Amps x .1 to
This parameter setting is determined by the motor nameplate..
Motor Base Frequency
P0.02
Range: 50/60/400
This parameter setting is determined by the motor nameplate.
Motor Base RPM
P0.03
Range: 375 to 24,000 RPM
This parameter setting is determined by the motor nameplate.
P0.04 Motor Maximum RPM
Range: P0.03 to 24,000 RPM
This parameter setting is determined by the needs of the application.
W : The Motor Maximum RPM parameter (P0.04) should never exceed the
ARNING
maximum RPM rating for the motor that you are using. If this information is not
readily available, consult your motor manufacturer.
P1.00 Stop Methods
Range: 00 Ramp to Stop
The application requires that this parameter be set to Ramp to Stop
because the motor needs to stop under power. (If the AC drive is set for
Coast to Stop, the AC drive will ignore the Deceleration Time setting.)
: If the Stop Method for the DURA
W
ARNING
the AC drive will ignore the (P1.02) setting for Deceleration Time.
1st Ed. Rev. D 05/2013
Chapter 3: Keypad Operation and Quickstart
460V series: 380/400/415/440/460/480
Drive Rated Amps x 1.0
01 Coast to stop
DURA
PULSE
Default Setting: 240
Default Setting: 480
Default Setting: Drive Rating (A)
Default Setting 60
Setting: 1725
Default Setting: 1750
Setting: 2000
Default Setting: P0.03
Default Setting: 00
PULSE AC drive is set for Coast to Stop,
AC Drive User Manual
Setting: 460
Setting: 2.6
Setting: 60
Setting: 00
