Appendix A: Accessories
Brake Resistor Dimensions (continued)
GS-4025-BR-ENC, GS-4030-BR-ENC, GS-4040-BR-ENC,
GS-4075-BR-ENC = 2 Units
Figure 7
(4) 1/2 CONDUIT K.O.
GS-4050-BR-ENC, GS-4060-BR-ENC,
GS-4100-BR-ENC = 2 Units
Figure 8
FRONT VIEW
(4) 1/2 CONDUIT K.O.
26 1/2 [673.1]
26 1/2 [673.1]
A–28 DURA
PULSE
FRONT VIEW
26 1/2 [673.1]
TOP VIEW
25 [635.0]
26 1/2 [673.1]
TOP VIEW
25 [635.0]
AC Drive User Manual
LEFT SIDE VIEW
THERMOSTAT (NC)
5 [127.0]
(4) 7/16 [11.11] DIA.
13
[330.2]
Units: inches[mm]
10 1/2
[266.7]
LEFT SIDE VIEW
THERMOSTAT (NC)
5 [127.0]
(4) 7/16 [11.11] DIA.
16
Units: inches[mm]
[406.4]
13 1/2
[342.9]
5 [127.0]
13 [330.2]
5 [127.0]
16 [406.4]
