Chapter 5: DURA
Status Monitor 2
GS3 Memory Address
(hexadecimal)
2101
Address Bit(s) Value
Bit(s) Binary (Decimal)
0 and 1
2
3 and 4
5 ~ 7
8
9
10
11
12
Frequency Command F (XXX.X)
Status location for the frequency setting of the AC drive.
Output Frequency H (XXX.X)
Status location for the actual operating frequency present at the T1, T2, and T3
terminal.
Output Current A
Status location for the output current present at the T1, T2, and T3 terminals.
DC-BUS Voltage d (XXX.X)
Status location for the DC Bus Voltage.
5–12 DURA
PULSE
PULSE MODBUS Communications
15 14 13 12 11
0 0 0 0 0
Status Monitor 2 - Memory Address h2101
AC Drive Status
00 (0) Drive operation stopped (STOP)
01 (1) Run to Stop transition
10 (2) Standby
11 (3) Drive operation running (RUN)
1 (4) JOG active
00 (0) Rotational direction forward (FWD)
01 (8) REV to FWD transition
10 (16) FWD to REV transition
11 (24) Rotational direction reverse (REV)
N/A Reserved
1 (32) Source of frequency determined by serial comm interface (P4.00 = 5)
1 (64) Source of frequency determined by AI terminal (P4.00 = 2, 3, 4 or 6)
1 (128) Source of operation determined by serial comm interface (P3.00 = 3 or 4)
1 (256) Parameters have been locked (P9.07 = 1)
N/A Copy command eable
AC Drive User Manual
10 9 8 7 6 5 4
0 0 0 0 0 1 0
h2101
3 2 1 0 Bits
0 0 1 0
Bit Values
(decimal)
h2102
h2103
h2104
h2105
