v Block Transfer Parameter 1
P9.11
v Block Transfer Parameter 2
P9.12
v Block Transfer Parameter 3
P9.13
v Block Transfer Parameter 4
P9.14
v Block Transfer Parameter 5
P9.15
v Block Transfer Parameter 6
P9.16
v Block Transfer Parameter 7
P9.17
v Block Transfer Parameter 8
P9.18
v Block Transfer Parameter 9
P9.19
v Block Transfer Parameter 10
P9.20
v Block Transfer Parameter 11
P9.21
v Block Transfer Parameter 12
P9.22
v Block Transfer Parameter 13
P9.23
v Block Transfer Parameter 14
P9.24
v Block Transfer Parameter 15
P9.25
Range for Block Transfer Parameters (P9.11-P9.25): P0.00 to P8.02, P9.99
The sequential block transfer parameters (P9.11 through P9.25) allow you to
"group" various miscellaneous non-sequential parameters, so that only one PLC
programming write instruction is required to update those parameters, instead of
three separate write instructions.
• Example:
Writing directly to three non-sequential parameters P1.00, P1.02, and P1.04
requires three separate write instructions from the PLC. However, those drive
parameters can be updated with only one PLC write instruction to the sequential
transfer blocks P9.11 through P9.13; if P9.11 is set to P1.00, P9.12 is set to P1.02,
and P9.13 is set to P1.04.
• Setting P9.99 (default) disables the Block Transfer Parameter.
1st Ed. Rev. D 05/2013
Chapter 4: AC Drive Parameters
DURA
PULSE AC Drive User Manual
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
Default Setting: P9.99
4–75
