AutomationDirect DURAPULSE Series User Manual page 156

Chapter 5: DURA
Parameter
P4.00
Source of Frequency Command
v P4.01
Analog Input Offset Polarity
v P4.02
Analog Input Offset
v P4.03
Analog Input Gain
P4.04 Analog Input Reverse Motion Enable
P4.05
Loss of AI2 Signal (4-20 mA)
v P4.11
Analog Output Signal
v P4.12
Analog Output Gain
P4.13**
2nd Source of Frequency Command
v P4.14**
2nd Frequency Command Offset Polarity
v P4.15**
2nd Frequency Command Offset
v P4.16**
2nd Frequency Command Gain
v P4.17**
Trim Frequency Reference
v P4.18**
Trim Mode Select
v P5.00
Jog
v P5.01
Multi-Speed 1
v P5.02
Multi-Speed 2
v P5.03
Multi-Speed 3
v P5.04
Multi-Speed 4
v P5.05
Multi-Speed 5
v P5.06
Multi-Speed 6
v P5.07
Multi-Speed 7
v P5.08
Multi-Speed 8
v P5.09
Multi-Speed 9
v P5.10
Multi-Speed 10
v P5.11
Multi-Speed 11
v P5.12
Multi-Speed 12
v P5.13
Multi-Speed 13
v P5.14
Multi-Speed 14
v P5.15
Multi-Speed 15
* For Modbus Decimal addresses used with CLICK PLCs,
insert another zero as the next-to-most-significant digit, e.g., 402333 instead of 42333.
** Some parameters are available only in later firmware versions of DURA
Refer to P9.39 and "DURA
v Parameter can be set during RUN Mode.
5–6 DURA
PULSE
PULSE MODBUS Communications
Parameter Memory Addresses (continued)
Description
Analog Parameters
Presets Parameters
Parameter Summary" in Chapter 4 for more information.
PULSE
AC Drive User Manual
Modbus
Hexadecimal
Decimal *
0400 41025
0401 41026
0402 41027
0403 41028
0404 41029
0405 41030
040B 41036
040C 41037
040D 41038
040E 41039
040F 41040
0410 41041
0411 41042
0412 41043
0500 41281
0501 41282
0502 41283
0503 41284
0504 41285
0505 41286
0506 41287
0507 41288
0508 41289
0509 41290
050A 41291
050B 41292
050C 41293
050D 41294
050E 41295
050F 41296
drives.
PULSE
1st Ed. Rev. D
Octal
2000
2001
2002
2003
2004
2005
2013
2014
2015
2016
2017
2020
2021
2022
2400
2401
2402
2403
2404
2405
2406
2407
2410
2411
2412
2413
2414
2415
2416
2417
05/2013
