INTRODUCTION

Victaulic VicFlex Style AQD-M Brackets connect the branch line directly to the sprinkler
and can be installed on round or square metal duct.
• Refer to the "Technical Data for Flexible Hoses" section.
• Refer to the "Important Installation Information" section.
STYLE AH2-CC FLEXIBLE HOSE ASSEMBLY
DRAWING
Item
1 Flexible Hose Assembly
2 Coupling Assembly
3 Identification Sleeve
4 No. 140 Male NPT or BSPT Thread x Groove Adapter Nipple*
* A No. 140 Male NPT or BSPT Thread x Groove Adapter (Item 4 above) is provided with
the shipment. This adapter is used only when connecting the Series AH2-CC Flexible
Hose to threaded sprinkler piping.
I-VICFLEX_98
2
Series AH2-CC Description
STYLE AQD-M BRACKET INSTALLATION
FOR ROUND OR SQUARE METAL
1
OR FRP DUCTS REV_A
3
