INSTRUCTIONS FOR USING THE STYLE AB6
ADAPTER FOR DRAINING THE ASSEMBLY
1. Slowly loosen and then remove the plug from the Style AB6 adapter. Allow the
assembly to drain.
2. After the assembly is drained completely, install the plug back into the Style AB6
adapter hand tight, plus 1 1/2 to 3 turns.

BULB PROTECTOR REMOVAL

• Sprinklers cannot operate properly with bulb protectors in place.
• Bulb protectors shall be removed from all sprinklers before the sprinkler system
is placed in service.
• DO NOT use any tools to remove bulb protectors.
Failure to follow these instructions will cause improper sprinkler operation,
resulting in death or serious personal injury and property damage.
1. Remove the bulb protector from all sprinklers carefully by hand before the sprinkler
system is placed in service.
I-VICFLEX_60
3. Reinstall the bulb protector onto the
sprinkler until the sprinkler system is
placed in service. Use caution when
reinstalling the bulb protector to prevent
damage to the bulb, deflector, and
frame arms. DO NOT use any tools to
reinstall the bulb protector
WARNING
STYLE AB6 BRACKET INSTALLATION FOR
FIRE PROTECTION SERVICE REV_A
