STYLE ABBA BRACKET ASSEMBLY DRAWING

Item
1 Gate
2 Adjustment Screw
3 Square Bar Retaining Screw
4 Bracket Body
5 Square Bar
6 Mounting Plate
STYLES ABBA/ABMM BRACKET INSTALLATION
FOR FIRE PROTECTION SERVICE REV_A
3
Description
6
5
4
1
2
I-VICFLEX_81
