STYLE AQD FLEXIBLE HOSE SPRINKLER FITTING
FRICTION LOSS DATA (FM)
• The following table contains FM friction loss data. Always refer to the applicable
"Listing and Approval Information – Flexible Hose and Bracket Combinations"
section to verify the listings/approvals for the particular flexible hose/bracket
combination.
Length of
Model inches/mm
AQD-36
AQD-48
AQD-60
AQD-72
TECHNICAL DATA FOR FLEXIBLE HOSES REV_A
Flexible Outlet Size
Hose inches/
Metric
36
915 DN15
48
1220 DN15
60
1525 DN15
72
1830 DN15
NOTICE
Equivalent Length
of 1-inch/DN25
Schedule 40 Pipe
feet/meters
1/2
1/2
1/2
1/2
Maximum
of 90° Bends
26.3
8.0
31.6
9.6
35.3
10.8
39.1
11.9
I-VICFLEX_181
Number
1
3
4
4
