SERIES AH1-LP/AH1-CC-LP FLEXIBLE HOSE
FRICTION LOSS DATA (FM)
• The following table contains FM friction loss data. Always refer to the applicable
"Listing and Approval Information – Flexible Hose and Bracket Combinations"
section to verify the listings/approvals for the particular flexible hose/bracket
combination.
Model
AH1-31-LP
AH1-CC-31-LP
AH1-36-LP
AH1-CC-36-LP
AH1-48-LP
AH1-CC-48-LP
AH1-60-LP
AH1-CC-60-LP
AH1-72-LP
AH1-CC-72-LP
¹ 3/4-inch/DN20 outlet data shown with K14.0 - For other K-factor friction loss data, refer to Victaulic
submittal 10.95.
7-inch/178-mm minimum bend radius.
2
A higher number of bends may be permitted, provided the sum of degrees is equal to or less than
3
the total maximum allowable degrees of bends. (e.g. Two 90° bends equal 180°. Three 90° bends
equal 270°). The minimum bend radius and maximum number of 90° offset (bends), stated in these
installation instructions, refer to the final installed condition of the hose.
NOTE: Differences in equivalent lengths are due to varying test methods, per UL 2443 and FM 1637
standards. Refer to these standards for additional information regarding friction loss test methods.
TECHNICAL DATA FOR FLEXIBLE HOSES REV_A
NOTICE
Length of
Flexible
Hose
inches/ Outlet Size
mm inches/Metric
DN15
31
790
DN20
DN15
36
915
DN20
DN15
48
1220
DN20
DN15
60
1525
DN20
DN15
72
1830
DN20
Equivalent
Length of
1-inch/DN25
Schedule 40
Pipe
1
meters
1/2 31.4
9.6
3/4 32.3
9.8
1/2 37.7
11.5
3/4 38.8
11.8
1/2 52.8
16.1
3/4 54.4
16.6
1/2 67.8
20.7
3/4 70.1
21.4
1/2 82.9
25.3
3/4 85.7
26.1
Maximum
Number
feet/ of 90°
2
Bends
2
2
3
4
4
I-VICFLEX_171
