STYLE AB7 BRACKET ASSEMBLY DRAWING

6
5
Item
1
2
3
4
5
6
*For the UL Listing, when the 48-inch/1220-mm length bracket is used, the maximum
sprinkler K-factor is K8.0 and the maximum spacing is 30-inches/762-mm. Square bar
length is in reference to nominal ceiling grid spacing.
I-VICFLEX_62
Sprinkler Fittings connect the sprinkler piping directly to the sprinkler
4
3
Style AB7 Description
24-inch/610-mm or 48-inch/1219-mm Square Bar*
Center Gate Assembly with Wing Nut
Style AB7 End Bracket with Wing Screw
#8 x 1/2-inch Self-Drilling Screw
Relocation Warning Label
1
Sheet Metal Screw
INSTALLATION INSTRUCTIONS REV_A
4
2
3
5
STYLE AB7 BRACKET
